Parameterizing OCR Checkpoints

Applies to TestComplete 15.63, last modified on April 10, 2024

In TestComplete, OCR checkpoints recognize text contents of a tested object using optical character recognition and verify that it matches the specified string pattern.

OCR checkpoints you create via the Create Checkpoint wizard use a hard-coded string pattern for verification. In other words, these checkpoints will always perform the same verification procedure checking the text contents against the same pattern.

If the text you want to verify changes between test runs, you may want to replace the checkpoint’s hard-coded string pattern with a parameter that gets the needed pattern before each test run. That is, you may want to parameterize your OCR checkpoint.

The image below demonstrates two OCR Checkpoint operations. One of them checks the tested object’s text contents against the hard-coded string value, the other one—against the value stored in keyword test parameter param1.

Parameterizing the OCR Checkpoint operation

The sections below describe how to parameterize OCR checkpoints.

In keyword tests

  1. Create a parameter that will pass the needed value to the checkpoint. It can be:

    For example, the image below shows the Param1 parameter of a keyword test:

    Creating a keyword test parameter to parameterize a checkpoint

    Click the image to enlarge it.

  2. In your keyword test, replace the hard-coded value of the checkpoint operation with the created parameter or variable:

    Parameterizing Checkpoint operation

    Click the image to enlarge it.

  3. Assign the needed value to the created parameter or variable:

    • If you use a test parameter, set its value when you run your test:

      • If you run it as part of the project’s test items sequence, set the test parameter in the Execution Plan editor of your project:

        Setting parameter value

        Click the image to enlarge it.

      • If you run your test from another test, set the parameter value when calling your test.

    • To set a variable value, you can use the Set Variable Value operation.

  4. Run the test with the needed parameter value assigned.

In scripts

  1. Define a parameter or variable that will pass the needed value to the checkpoint. It can be:

    For example, the code snippet below shows how to declare the Param1 parameter of a script routine:

    JavaScript, JScript
    Python
    VBScript
    DelphiScript
    C++Script, C#Script
    Copy Code

    JavaScript, JScript

    function CheckTextContents(Param1)
    {
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText("Hard-coded baseline string");
      …
    }

    Python

    def CheckTextContents(Param1):
      …
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText("Hard-coded baseline string")
      …

    VBScript

    Sub CheckTextContents(Param1)
      …
      Call OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText("Hard-coded baseline string")
      …
    End Sub

    DelphiScript

    procedure CheckTextContents(Param1);
    begin
      …
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText('Hard-coded baseline string');
      …
    end;

    C++Script, C#Script

    function CheckTextContents(Param1)
    {
      …
      OCR["Recognize"](Aliases["SampleApp"]["MainForm"]["Edit"])["CheckText"]("Hard-coded baseline string");
      …
    }

  2. Replace the hard-coded parameter of the OCR.Recognize.CheckText method with the created variable or parameter:

    JavaScript, JScript
    Python
    VBScript
    DelphiScript
    C++Script, C#Script
    Copy Code

    JavaScript, JScript

    function CheckTextContents(Param1)
    {
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText(Param1);
      …
    }

    Python

    def CheckTextContents(Param1):
      …
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText(Param1)
      …

    VBScript

    Sub CheckTextContents(Param1)
      …
      Call OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText(Param1)
      …
    End Sub

    DelphiScript

    procedure CheckTextContents(Param1);
    begin
      …
      OCR.Recognize(Aliases.SampleApp.MainForm.Edit).CheckText(Param1);
      …
    end;

    C++Script, C#Script

    function CheckTextContents(Param1)
    {
      …
      OCR["Recognize"](Aliases["SampleApp"]["MainForm"]["Edit"])["CheckText"](Param1);
      …
    }

  3. Assign the needed value to the parameter or variable:

    • If you use a script parameter, you set the parameter value when you call the script, either from another script routine or as the project’s test item.

      The image below shows how to set the parameter value when running the script routine as a project’s test item:

      Setting parameter value

      Click the image to enlarge it.

    • If you use a variable, set its value in the script before the script executes the checkpoint.

  4. Run the script with the needed parameter value assigned.

Obtain parameters from external files

The parameter you pass to OCR checkpoints in tests can contain data from external storages, for example, from databases, or text or Excel files. For more information on this, see Parameterizing Tests Using External Data Sources.
